510-33 SLS200 Air Jet Sieve

SLS200 Air Jet Sieve can’t be found in the international market. We can only find it in domestic market. The types which are very common in the international market and Chinese market are HMKTest’s HMK-200 Air Jet Sieve and Alpine’s 200LS-N Air Jet Sieve.

Air Jet Sieve Open Mesh

The same with HMK-200 Air Flow Sieve, 200LS-N Air Jet Sieve is designed for rapid and accurate sieving of the powder（2um~4000um）in modern laboratory. Because the fine powder with less than 4000um particle size is prone to agglomeration, static electricity and blockage of the mesh of the analysis sieve during the sieving process, the traditional vibrating sieve has been unable to accurately and rapidly sieve such fine powder. These powder include paint, coal ash powder, flour, Chinese and western medicine powder, glass fiber powder and other materials. HMK-200 Air Jet Sieve adopts a specially designed rotating jet slot and electrostatic removal device to perfectly meet the rapid and accurate sieving results. It is widely used in chemical, paper, metallurgy, building materials, medicine, food, rubber, plastics, machinery, mining and other industries powdery materials classification.

Features

1. Reliable sieving results reproducibility, high efficiency sieving effect, saving time
2. LCD digital display and accurate control sieve time
3. Digital display vacuum degree, adjust the vacuum generator to ensure sieving reproducibility
4. Specially designed rotating air jet slot, uniformly scattered materials to eliminate aggregation
5. Fully transparent window sieve cover for real-time and continuous monitoring of sieving status and the whole process.
6. Optional antistatic configuration, sieve electrostatic material without worry
7. The material preheater can be selected to sieve the strong moisture absorbing powder easily.
8. Stainless steel case, wear-resistant anti-corrosion paint on the surface of the instrument, easy to clean, durable.
9. Sieve standard：accord with standard ISO 3310-1、DIN EN10204.21 and ASTM E 11. Stainless steel material, surface polishing treatment. Either copper or nylon mesh.

Working principle

The air flow from the rotating air jet groove under the mesh is continuously dredged through the mesh hole, and the fine powder is continuously thrown up to disperse it back to the sieve surface. In addition, under the negative pressure of vacuum generator (industrial vacuum cleaner) and the gravity of materials, the micro powder smaller than the particle size of the sieve quickly pass through the sieve to achieve rapid and accurate sieving results. HMK-200 meets the international and domestic quality control standards for paint, cement, construction, coal, medicine and other industries.

Specifications

Sieve tray diameter：200mm

Time setting：1-99 minutes，liquid crystal display, adjustable

Connect the vacuum cleaner, the vacuum of the sieve can be set, and LCD panel display

Instrument dimension：width x height x depth 326mm x 270mm x 425mm
